FC-101P15KT4E20H4XXCXXXSXXXXAXBXCXXXXDX
VLT® HVAC Drive FC- 101
(P15K) 15 KW / 20 HP, Three phase
380 – 480 VAC, (E20) IP20 / Chassis
RFI class A1 (C2)
No brake chopper
No Loc. Cont. Panel
Coated PCB, No Mains Option
No A Option, No B Option
No C1 option, No D option
Frame: H4
Range of temperature display:－45～150℃ (－45~150℉)
Range of set temperature:－45～45℃ (－40~113℉)
Accuracy:±1℃(±2℉)
Compressor: N.O. 16A/250VAC
Defrost: N.O. 10A/250VAC
Evap. Fan: N.O. 5A/250VAC
Socket and plate in ceramic : 300 V max
Hook and contact in stainless steel : 270 °C max
Rivet in nickel plated brass : 270 °C max
PTFE Cable : 250 °C max
– Consumes less energy
– Reduces current draw
– Lowers fuel usage
– Produces less wear and tear
– Life expectancy of up to 10 times longer than comparable brushed fans
– Extends the life of your vehicle’s alternator
• Triac, phase angle controller
• 50…700W, suitable loads: resistor, fan motor and transformer
• Base level adjustment
• 0…5V, 0…10V or 4…20mA control
• Aux. voltage for potentiometer use
• Galvanic isolation
• Rail base mountable
ERRECOM Extreme Ac & Refrigeration Leak Stop 60ml Cartridge with HVAC/R adapters (1/4 SAE + 5/16 SAE)
2 PAIRS – 1 Box
Highly safe formula: Extreme is polymer-free, therefore it does not react with moisture and oxygen and does not clog air conditioning and refrigeration systems.
